Specification

• Printer Model

  GP-D300II

• Print Method

  Direct thermal

• Print Command

  Compatible with ESC/POS, Star commands

• Resolution

  203DPI

• Print Speed

  300mm/s

• Print Width

  72mm

• Print Head Temperature Detect

  Thermal sensitive resistance

• Print Head Position Detect

  Microswitch

• Paper Detect

  Transmissive sensor

• Memory

  FLASH: 256K

• Interface

  Standard: Serial+USB+Ethernet+Cash drawer
  Optional: USB+Bluetooth +Cash drawer USB+WiFi +Cash drawer USB+Bluetooth+WiFi+Cash drawer

• Graphics

  Support different density bitmap printing

• Barcode Type

  UPC-A / UPC-E / JAN13(EAN13) / JAN8(EAN8) / ITF / CODABAR / CODE39 / CODE93 / CODE128 / QRCODE / PDF417 / Data Matrix

• Character Set

  Standard: GB18030 Simplified Chinese
  Optional: GB18030, Traditional Chinese BIG5, Japanese font, Korean KSC5601(One or more Character set supported)

• Character Enlargement / Rotation

  1 ~8 times enlargement in portrait and landscape orientation, rotating printing, inverted printing

• Media Type

  Thermal roll paper (include environmental paper), Blackmark paper roll

• Media Width

  79.5士0.5mm

• Media Roll Outer Diameter

  Max. 82mm

• Media Thickness

  0.06-0.08mm

• Media Handle

  Partial-cut

• Media Output Method

  Top paper output

• Sensor Location

  Middle

• Wall Mounting

  Support

• Power Input

  DC 24V 2.5A

• Cash Drawer Output

  DC 24V 1A

• Working Environment

  0~45℃, 20%~90% non-condensing

• Storage Environment

  -20~55℃, 20%~93% non-condensing

• Printer Weight

  1.05kg

• Printer Dimension

  177mm×144mm×132.5mm

• Packing Dimension

  260mm×159mm×151mm

• Print Head (reliability)

  150km

• Cutter (reliability)

  1.5 million times

• Printer Certificate

  CCC、RoHS
