Specification

• Level

  Standard

• Resolution

  8 dots/mm (203DPI)

• Printing Method

  Thermal Transfer & Direct Thermal

• Max. print speed

  152 mm (6")/second

• Max. print width

  54 mm (2.13")

• Max. print length

  2,794 mm (110")

• CPU

  400 MHz, 32 bits, ARM9

• Memory RAM

  64 MB SDRAM

• Memory ROM

  32 MB Flash / 128 MB Flash(factory option)

• Interface

  • USB 2.0 High Speed 480Mbps
  • USB Host 2.0, for scanner or PC keyboard
  • RS-232(factory option)
  • Internal Ethernet 10/100Mbps(factory option)
  • Internal Bluetooth 4.0 (factory option)
  • Internal WiFi (factory option)

• Real Time Clock

  N/A

• Buzzer

  N/A

• Dealer options

  Guillotine cutter (full cut and partial cut)

• Sensors

  Head open sensor, Ribbon end sensor, Reflective sensor (moveable), Front-Reflective sensor

• Power

  External universal switching power supply
  Input: AC 100-240V, 2.5A, 50-60Hz. Output: DC 24V, 2.5A, 60W

• User Interface

  • 1 power switch
  • 2 buttons (Feed & Pause)
  • 3 LEDs (Online, Error, Ribbon status)

• Internal fonts

  • 8 alpha-numeric bitmap fonts
  • True type font engine (need to download scalable font file)

• 1D Barcode

  Code 11, Code 39, Code 93, Code 128 (subsets A, B, C), UPC-A, UPC-E, UCC-128, Codabar, EAN/JAN-8, EAN/JAN-13, Interleaved 2 of 5, ITF14, MSI Pleassy, PostCode, Telepen

• 2D Barcode

  QR Code, Micro QR Code, PDF417, Micro PDF417, Grid Matrix, MaxiCode, Aztec Code, Data Matrix

• Rotation

  Font and barcode support 0, 90, 180, 270 degree rotation

• Printer language

  Compatible to TSPL, EPL, EPL 2, ZPL, ZPL II, DPL

• Media type

  Continuous, die-cut, black mark, fan-fold, notched (outside wound)

• Media width

  15 ~ 63 mm (0.59" ~ 2.48")

• Media thickness

  0.06 ~ 0.19mm (2.36 ~ 7.48 mil)

• Media core diameter

  25.4 mm (1")

• Label roll capacity

  127 mm (5") OD

• Label length

  5 ~ 2,794 mm (0.2"~110")

• Physical dimension

  160mm(W) x 170mm(H) x 280mm (L)

• Net Weight

  1.8kg

• Enclosure

  ABS plastic

• Ribbon

  300 meters long, max. OD 66mm, 1"core (ink coated outside)

• Ribbon width

  30 ~ 60 mm (1.18" ~ 2.36")

• Environment condition

  Operation: 5~40°C, 25~85% non-condensing
  Storage: -40~60°C, 10~90% non-condensing

• Environment concern

  Comply with RoHS, REACH, WEEE

• Accessories

  • Driver and software CD
  • Quick start guide
  • USB cable
  • Power cord
  • External universal switching power supply
  • 1" ribbon spindle x 2
