80mm Thermal Receipt Printer GA-G3

Thermal Receipt Printer

80mm Thermal Receipt Printer GA-G3
80mm Thermal Receipt Printer GA-G3
80mm Thermal Receipt Printer GA-G3
80mm Thermal Receipt Printer GA-G3
80mm Thermal Receipt Printer GA-G3
80mm Thermal Receipt Printer GA-G3
80mm Thermal Receipt Printer GA-G3

Product Features

Front-exit and upper-exit with auto cutter, cube design

300dpi print resolution to set new industry standard

Support 50% more content printed compared with 203dpi resolution printing in the same length page

Help reduce paper usage by 30% at least Fast Transaction Time

Receipt printing speed at 200mm/sec max.

Various interface available (Serial / USB / Ethernet / RJ11 cash drawer / Bluetooth / 4G network)

Application Industries

  • Retail

    Retail

  •  Health Сare

    Health Сare

  • Entertainment & Service Industry

    Entertainment & Service Industry

Specification

  • Printer Model

    GA-G3
    GA-G2

  • Print Method

    Direct Thermal

  • Emulation

    EPSON / Star

  • Paper Width

    79.5 ±0.5 x 80mm
    57.5±0.5 x 80mm

  • Print Width

    72mm

  • Resolution

    GA-G3: 12dots/mm(300DPI)
    GA-G2: 8dots/mm(203DPI)

  • Max. Paper Diameter

    80mm

  • Print Speed

    GA-G3: 200mm/sec
    GA-G2: 300mm/sec

  • Paper Thicknes

    0.06~0.08mm

  • Interface

    USB 2.0+RS-232
    Ethernet+RJ11 CashDrawer
    Bluetooth (optional)
    Wi-Fi (optional)
    4G (optional)

  • Data Buffer

    Buffer: 128K bytes (TBD)
    SRAM: 192K (TBD)
    ROM: 512k bytes (TBD)
    Flash: 16M bytes (TBD)

  • Barcode Type

    1D: UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13,CODE39, ITF, CODABAR, CODE93,CODE128
    2D: QRCODE

  • Power Supply

    External universal switching power supply
    Input:AC 100-240V, 1A, 50-60Hz,Output:DC 24V, 2.5A, 60W

  • Cash Drawer

    24V/1A

  • Print Head Life

    150 km print length or 100 million pulses

  • Auto Cutter Life

    1.5 million cuts

  • Operating System

    Support Windows、Linux、Mac Driver

  • Net Weight

    1.5KG

  • Dimension

    130mm(L) x 130mm(W) x 130mm(H)

Operation film

  • 22

    March

    Receipt printer

    80mm Receipt printer: Product Overview

    80mm Receipt printer: Product Overview

    GA-G3
